Antec Infinity Matrix IM360 ARGB - three 120mm ARGB fans on one 360mm single frame.
The IM360 is a single-frame triple fan: three 120mm impellers moulded into one 364 x 124 x 28mm frame, so it mounts in one step and needs one set of screws instead of three. The assembly runs 800 to 1800 RPM on a single 4-pin PWM connector for up to 134.43 CFM at 1.48 mmAq, at 19.7 to 32.8 dB(A), on hydraulic bearings rated 40,000 hours. Lighting is 56 addressable RGB LEDs across four-sided infinity mirrors, dual light strips and hub rings, on its own 3-pin 5V cable, with double-sided silicone anti-vibration pads on the frame.
Key Features
-
Single-frame triple fan — 364 x 124 x 28mm one-piece frame - one mount, one screw set, no gap between fans.
-
800-1800 RPM on 4-pin PWM — One PWM connector drives all three impellers; 61.51 to 134.43 CFM.
-
134.43 CFM at 1.48 mmAq — Radiator-grade static pressure at 19.7-32.8 dB(A).
-
56 addressable RGB LEDs — Four-sided infinity mirror plus dual light strips and hub rings, on a 3-pin 5V ARGB connector.
-
Double-sided silicone pads — Anti-vibration on both faces of the frame, and two independent cables for clean routing.
Specifications
| Fan Type |
360mm PWM fan kit (3 x 120mm, single frame) |
| Dimensions |
364 x 124 x 28mm |
| Bearing |
Hydraulic bearing, 40,000 hours |
| Lighting |
Addressable RGB - 56 LEDs, 3-pin 5V ARGB |
| Fan Speed |
800+/-200 to 1800+/-10% RPM (4-pin PWM) |
| Airflow / Pressure |
61.51-134.43 CFM / 0.35-1.48 mmAq |
| Noise |
19.7-32.8 dB(A) |
| Rated Voltage / Current |
Fan DC 12V 0.5A / LED DC 5V 1.4A |
| Connectors |
FAN: 4-pin PWM / LED: 3-pin ARGB |
| Mounting |
360mm radiator spacing, front or top of a mid-tower |
What's in the box
- 1x Infinity Matrix 360 ARGB single-frame fan (4-pin PWM + 3-pin ARGB cables)
- Mounting screws
- Requires a motherboard ARGB header or an ARGB controller - no controller in the box
Who it's for
A 360mm radiator or a front intake where three separate fans would leave gaps and three sets of cables to hide.
