25G4S |
| Panel |
24.5" (Fast IPS) |
| Pixel Pitch (mm) |
0.2832 (H) × 0.2802 (V) |
| Effective Viewing Area (mm) |
543.74 (H) × 302.62 (V) |
| Brightness (typical) |
400 cd/m² |
| Contrast Ratio |
1000 : 1 (Typical) MEGA DCR |
| Response Time |
0.3ms (MPRT) / 1ms (GtG) |
| Viewing Angle |
178° (H) / 178° (V) (CR > 10) |
| Color Gamut |
NTSC 100% (CIE1976) / sRGB 115% (CIE1931) / DCI-P3 91% (CIE1976) |
| Color Accuracy |
Delta E < 2 |
| Optimum Resolution |
1920 × 1080 @ 310Hz (OC)– DisplayPort1.4; 1920 × 1080 @ 300Hz – DisplayPort1.4; 1920 × 1080 @ 240Hz – HDMI2.0 |
| Display Colors |
16.7 Million |
| Signal Input |
HDMI 2.0 × 2, DisplayPort 1.4 × 1 |
| HDCP Version |
HDMI: 2.2 / DisplayPort: 2.2 |
| USB Hub |
No |
| Power Supply |
Internal 100 - 240V～1.5A, 50 / 60Hz |
| Power Consumption (typical) |
30W |
| Speakers |
No |
| Line in & Earphone |
Earphone |
| Wall-Mount |
100mm x 100mm |
| Adjustable Stand |
Height: 130mm, Swivel: -30° ~ 30°, Pivot: -90°~ 90°, Tilt: -5° ~ 23° |
| Product without Stand (mm) |
324.8 (H) × 560.1 (W) × 52.1 (D) |
| Product with Stand (mm) |
381.1~499.0(H) × 560.1 (W) × 240.0 (D) |
| Packaging (mm) |
481 (H) × 780 (W) × 162 (D) |
| Product without Stand (kg) |
2.81 |
| Product with Stand (kg) |
4.22 |
| Product with Packaging (kg) |
7.55 |
| Cabinet Color |
Black & Red |
| Regulatory Approvals |
CE / CB / FCC / RoHS |
| * Design and specifications are subject to change without notice. |
