| Panel Size |
|
| Active Display Area (mm) |
|
| Curvature |
|
| Panel Type |
Rapid IPS with Mini-LED (1152 Zones)
|
| Panel Resolution |
Normal: 3840 x 2160 (UHD)
|
|
Dual Mode: 1920 x 1080 (FHD) |
| Pixel Pitch (H x V) |
0.15525 (H) x 0.15525 (V)
|
| Aspect Ratio |
|
| Brightness (nits) |
|
| Contrast Ratio |
HDR: 1000 cd/m² (Peak) |
| DCR |
|
|
|
| Signal Frequency |
Normal: 180~356KHz (H) / 48~160Hz (V)
|
|
Dual Mode: 180~356KHz (H) / 48~320Hz (V) |
| ACTIVATED RANGE |
|
|
Dual Mode: 48~320Hz |
| Refresh Rate |
|
|
Dual Mode: 320Hz |
| Response time |
|
| DYNAMIC REFRESH RATE TECHNOLOGY |
|
| HDR Support |
|
| Video ports |
1x DisplayPort 1.4a (HBR3)
|
|
2x HDMI™ 2.1 (UHD@160Hz) |
|
1x Type-C (DP alt.) w/ 98W Power Delivery |
| Audio ports |
|
| Viewing Angle |
|
| Adobe RGB / DCI-P3 / sRGB |
100% / 98% / 140% (CIE1976 Standard)
|
| Surface Treatment |
|
| Display Colors |
1.07B, 10 bits (8 bits + FRC)
|
| Console Mode |
Supported Resolution & Refresh Rate:
|
|
1080p: 60Hz and 120Hz |
|
1440p: 60Hz and 120Hz |
|
2160p: 60Hz and 120Hz |
|
|
|
HDMI™ CEC: Supported |
|
VRR: PS5 and Xbox Supported |
| Frameless Design |
|
| PIP / PBP Function |
|
| Power Type |
|
| Power Input |
|
| Adjustment (Tilt) |
|
| Adjustment (Swivel) |
|
| Adjustment (Pivot) |
|
| Adjustment (Height) |
|
| Kensington Lock |
|
| VESA Mounting |
|
| Dimension with Stand (W x D x H) |
613.1 x 202.38 x 400.85 mm
|
|
(24.14 x 7.97 x 15.78 inch) |
| Dimension without Stand (W x D x H) |
613.1 x 68.77 x 375.31 mm
|
|
(24.14 x 2.71 x 14.78 inch) |
| Weight (NW / GW) |
8.2 kg (18.08 lbs) / 12.4 kg (27.34 lbs)
|
| Carton Dimension (W X D X H) |
|
|
(35.63 x 7.68 x 18.50 inch) |
| Accessories |
1x DP Cable (1.4a), 1x HDMI™ Cable (2.1), 1x USB Type-B to A Cable, 1x USB Type-C Cable, 1x Power Cord (C5), 1x AC Adaptor, 1x Quick Guide, 4x VESA Wall Mount Screw
|
| Note |
HDMI™: Normal (UHD): 3840 x 2160 (Up to 160Hz)
|
|
Dual Mode (FHD): 1920 x 1080 (Up to 320Hz) |
|
DisplayPort: Normal (UHD): 3840 x 2160 (Up to 160Hz) |
|
Dual Mode (FHD): 1920 x 1080 (Up to 320Hz) |
|
Type-C: Normal (UHD): 3840 x 2160 (Up to 160Hz) |
|
Dual Mode (FHD): 1920 x 1080 (Up to 320Hz) |
|
Support: HDMI™ CEC, PIP/PBP, KVM |
