| Performance |
| Suitable location |
Processor |
| Pulse-width modulation (PWM) support |
Yes |
| Type |
Liquid cooling kit |
| Supported processor sockets |
LGA 1150 (Socket H3), LGA 1151 (Socket H4), LGA 1155 (Socket H2), LGA 1156 (Socket H), LGA 1200 (Socket H5), LGA 1700, Socket AM4, Socket AM5, Socket TR4, Socket sTRX4 |
| Maximum airflow |
77.4 cfm |
| Number of fans |
2 fan(s) |
| Quantity per pack |
1 pc(s) |
| Pump noise level |
21.2 dB |
| Pump motor speed |
2800 RPM |
| Fan speed (max) |
2800 RPM |
| Pump's mean time to failure (MTTF) |
50000 h |
| Fan's mean time to failure (MTTF) |
100000 h |
| Design |
| Number of fans |
2 fan(s) |
| Material |
Aluminium, Rubber |
| Illumination colour |
Multi |
| Product colour |
Black |
| Cable length |
3.5 m |
| Illumination LED |
Yes |
| Tube material |
Rubber |
| Display type |
IPS |
| Display size (HxV) |
320 x 240 mm |
| Power |
| Rated current |
0.3 A |
| Fan power consumption |
3.36 W |
| Pump power consumption |
4 W |
| Fan current |
0.28 A |
| Weight & dimensions |
| Fan dimensions (W x D x H) |
120 x 120 x 25 mm |
| Cable length |
3.5 m |
| Package width |
5 mm |
| Radiator width |
27.3 cm |
| Radiator depth |
12 cm |
| Radiator height |
2.7 cm |
| Waterblock width |
9.5 cm |
| Waterblock depth |
9.5 cm |
| Waterblock height |
8.35 cm |
| Technical details |
| Illumination LED |
Yes |
| Packaging data |
| Package type |
Box |
| Packaging content |
| Package type |
Box |
| Other features |
| Built-in display |
Yes |
| Tube material |
Rubber |
BE AHEAD, POP YOUR STYLE
The MPG series brings out fashionable products by showing extremely unique styles and expressing a conceited attitude towards the challenge of the gaming world. With extraordinary performance and style, the MPG series defines the future of gaming fashion.
UNRIVALED RAPID COOLING
MSI’s exclusive TORX FAN 4.0 provides concentrated airflow to the radiator for the most rapid heat dissipation.
TORX FAN 4.0
Inspired by teamwork, MSI’s exclusive TORX FAN 4.0 has two fan blades working as one with an outer ring design.
CONCENTRATED
COOLING PERFORMANCE
A 60mm fan is placed within the water block to help dissipate heat for the M.2 SSD, CPU VRMs, and surrounding components.
2.4" CUSTOMIZABLE IPS DISPLAY
The MPG CORELIQUID D Series comes with a 2.4" IPS display capable of displaying hardware information, GIF, MP4, photos, texts, and live weather information.
EVAPORATION PROOF TUBING
MPG CORELIQUID D Series’ tubing is constructed with three layers of netted plastic with a reinforced mesh exterior.
MYSTIC LIGHT COMPATIBLE
Show off your colors with full ARGB customization on the fans and cooling block.
CONTROL IN YOUR HANDS
Through MSI’s exclusive software, you can independently control all of the fans’ speed according to your preference for cooling or for silence.
TOTAL CONTROL IN YOUR HANDS
Everything ranging from MPG CORELIQUID D Series’ fan speed to the ARGB lighting to the IPS display can be adjusted through the MSI Center.![]()
![]()
![]()
