| HARDWARE FEATURES |
| Interface |
3× 10/100/1000Mbps RJ45 LAN Ports, |
| 1× 10/100/1000Mbps RJ45 WAN/LAN Port, |
| 1× RJ11 Port, |
| 1× USB 2.0 Port |
| Button |
WPS Button, Wi-Fi On/Off Button, Reset Button |
| External Power Supply |
12V/1A |
| IEEE Standards |
IEEE 802.3, IEEE 802.3u, 802.3ab |
| VDSL2 Standards |
ITU G.993.2, Up to 17a profile (POTS) |
| ITU-T G.993.5 (G.vector) |
| ITU-T G.998.4 (G.INP) |
| ADSL Standards |
Full-rate ANSI T1.413 Issue 2, |
| ITU-T G.992.1(G.DMT), |
| ITU-T G.992.2(G.Lite), |
| ITU-T G.994.1 (G.hs), |
| ADSL2 Standards |
ITU-T G.992.3 (G.DMT.bis) |
| ADSL2+ Standards |
ITU-T G.992.5 |
| Dimensions ( W x D x H ) |
8.5 × 4.9 × 1.2 in (215.6 × 124.6 × 31.6 mm) |
| Antenna Type |
2× fixed Omini-Directional antennas |
| WIRELESS FEATURES |
| Wireless Standards |
IEEE 802.11ac/n/a 5GHz, IEEE 802.11b/g/n 2.4GHz |
| Frequency |
2.4 GHz and 5 GHz |
| Signal Rate |
867Mbps at 5 GHz, 300Mbps at 2.4 GHz |
| Wireless Functions |
Enable/Disable Wireless Radio, WMM, Wireless Statistics |
| Wireless Security |
64/128-bit WEP, WPA/WPA2, WPA-PSK/WPA2-PSK encryptions |
| Transmission Power |
<20dBm (2.4 GHz), <23dBm (5 GHz) |
| Wireless Schedule |
Support 2.4 GHz and 5 GHz Wireless Schedule |
| SOFTWARE FEATURES |
| Security |
NAT Firewall, SPI Firewall, Access Control, Service Filtering, Denial of Service (DoS), SYN Flooding, Ping of Death, IP and MAC Address Binding |
| Operating Modes |
VDSL/ADSL Modem Router, Wireless Router, 3G/4G Router |
| Management |
Web-Based Configuration (HTTP / HTTPS ), Remote management, |
| Command Line Interface, SSL for TR-069, SNMP v1/2c, Firmware Upgrade, Diagnostic Tools, Free Online Firmware Update |
| DHCP |
Server, Client, DHCP Client List, Address Reservation, DHCP Relay |
| Port Forwarding |
Virtual Server, Port Triggering, DMZ, ALG, UPnP |
| Dynamic DNS |
DynDns, NO-IP, TP-Link |
| VPN |
OpenVPN, PPTP VPN, IPSec VPN |
| Protocols |
Supports IPv4 and IPv6 |
| ATM/PPP Protocols |
ATM Forum UNI3.1/4.0, PPP over ATM (RFC 2364), PPP over Ethernet (RFC2516), IPoA (RFC1577/2225), MER\IPoE (RFC 1483 Routed), Bridge (RFC1483 Bridge), PVC – Up to 8 PVCs |
| Advanced Features |
Parental Controls, Network Address Translation(NAT), Port Mapping |
| (Grouping), Static Routing, DDNS, IGMP V1/V2/V3 |
| Guest Network |
2.4GHz Guest Network, 5GHz Guest Network |
| OTHERS |
| Certification |
CE, RCM, RoHS |
| Package Contents |
AC1200 Wireless MU-MIMO VDSL/ADSL Modem Router Archer VR400 |
| External Splitter |
| RJ11 DSL Cable |
| RJ45 Ethernet Cable |
| Power Adapter |
| Quick Installation Guide |
| System Requirements |
Microsoft Windows 98SE, NT, 2000, XP, Vista™ or Windows 7, 8, 8.1, 10, macOS, NetWare, UNIX or Linux |
| Internet Explorer 11, Firefox 12.0, Chrome 20.0, Safari 4.0, or other |
| Java-enabled browser |
| Subscription with an internet service provider (for internet access) |
| Environment |
Operating Temperature: 0℃~40℃ (32℉ ~104℉) |
| Operating Humidity: 10%~90% non-condensing |
